Starlight Xpress Camera Lodestar X2 Autoguider Color
zoom_out_map
chevron_left chevron_right

Our company is involved in preparing official permits from the Polish Ministry of Development and Technology, which allows us to export all dual-use drones, optics, and portable radiophones without VAT on the Polish side / and without VAT on the Ukrainian side.

Starlight Xpress Camera Lodestar X2 Autoguider Color

While the original Lodestar utilized the ICX429 Exview chip from Sony, renowned for its exceptional sensitivity, Sony has now upgraded it to the ICX829. This latest 'Exview 2' chip boasts significantly improved Quantum Efficiency (QE) and reduced read noise, effectively doubling the Lodestar's sensitivity and adding nearly a full magnitude to the minimum guide star brightness.

636.33 $
Tax included

517.34 $ net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

The Lodestar X2 represents a notable advancement over the highly regarded Lodestar autoguider.

While the original Lodestar utilized the ICX429 Exview chip from Sony, renowned for its exceptional sensitivity, Sony has now upgraded it to the ICX829. This latest 'Exview 2' chip boasts significantly improved Quantum Efficiency (QE) and reduced read noise, effectively doubling the Lodestar's sensitivity and adding nearly a full magnitude to the minimum guide star brightness.

Additionally, Starlight Xpress has redesigned the boards to accommodate a standard RJ12 guide socket, addressing concerns from users regarding the fragility of the previous 'ZH' cable socket.



Specifications:

Capacity:

Sensor Type: CCD-chip (ICX829AL Sony Exview interline)

Megapixel: 0.4

Connection (to the Telescope): C-Mount

Bit Depth (Bit): 16

Type of Camera: Astro CCD Camera

Interfaces:

USB 2.0, RJ12

Power Supply: USB

Autoguider: Yes

Resolution Photograph (Pixel): 752x580

Pixel Size: 8.2

Active Cooling: No

Color Camera: Yes

Size of Chip (mm): 6.4 x 4.75

Full Well Capacity: 50,000

Dark Current: 0.1

Reading Noise: 6

Quantum Efficiency: 77% @600nm, 45% @500nm, 45% @700nm

Chip Diagonal (mm): 8

Equipment:

Filter Wheel: No

General:

Weight (g): 85

Color: Black

Material: Aluminium

Diameter (mm): 32

Length (mm): 86

Area of Application:

Autoguider: Yes

Moon & Planets: No

Nebulae & Galaxies: No

Data sheet
