DJI Zenmuse S1 Spotlight (CP.EN.00000650.01)

The Zenmuse S1 is DJI's first spotlight developed for multi-payload drone platforms, compatible with the Matrice 350 RTK, Matrice 300 RTK, and Matrice 400. Using LEP technology, it delivers high brightness and long-distance illumination, with several lighting modes available. This makes it especially suitable for public safety, emergency rescue, inspections, and other nighttime operations.

Important Information

• Before using the spotlight for the first time, download and review the safety guidelines and user manual from the DJI official website.

• Using the spotlight at night may interfere with obstacle avoidance systems. You may disable obstacle avoidance if needed, and should operate the drone and spotlight in open, spacious areas.

• Never look directly at the spotlight from close range to avoid potential harm. Prioritize safety at all times.

• Avoid touching the spotlight lens coating with your hands or scratching it with hard objects, as this can decrease light output efficiency and affect brightness and performance.

Package Contents

• Zenmuse S1 spotlight

• Lens protection cover

• Carrying case

• Lens cleaning cloth

Specifications

Weight: 760±10 g
Dimensions: 125×152×171 mm (length × width × height)
Rated Power: 68 W
Maximum Central Illuminance: 35 lux at 100 meters (Both On mode)
Effective Illumination Distance: 500 meters (Both On mode)
Supported Aircraft: Matrice 400, Matrice 350 RTK, Matrice 300 RTK (DJI RC Plus required for Matrice 300 RTK)
Ingress Protection Rating: IP54
Operating Temperature: -20°C to 40°C (-4°F to 104°F)
