RED V-RAPTOR XL 8K VV (V-Lock)

The V-RAPTOR XL 8K VV Camera, powered by a V-mount from RED DIGITAL CINEMA, delivers versatile 8K VV video capture, REDCODE raw and Apple ProRes recording, and 1080p streaming, all housed in a sleek design optimized for professional crew use. This successor to the V-RAPTOR introduces internal ND filters and an interchangeable lens mount, including the ARRI PL mount. Its industry-standard interface boasts three 12G/6G/3G-SDI outputs, versatile power outputs, timecode and genlock ports, and a V-mount battery plate.

Key Features:

Integrated Pro Interfaces: Designed for seamless integration with high-end camera accessories, featuring built-in wireless genlock and timecode, and multiple video outputs including 12G/6G/3G-SDI.

Interchangeable Lens Mount: Comes with an ARRI PL lens mount, swappable with a separately available Canon EF mount, allowing for compatibility with a wide range of lenses.

Internal ND Filters: Motorized clear and 2 to 7-stop ND filters with precise exposure control increments of 1/3, 1/4, and 1-stop.

Streamlined Design: The V-RAPTOR XL camera rig boasts a sleek and accessible form factor, enhanced by its built-in interfaces.

Package Includes:

• RED DIGITAL CINEMA V-RAPTOR XL 8K VV Cinema Camera (V-Mount)
• V-RAPTOR XL PL Mount
• V-RAPTOR XL PL Mount Shim Pack
• AC Power Adapter (270W)
• 3-Pin XLR to 4-Pin LEMO 2B Power Cable (10')
• RED Logo Sticker

Specification

Imaging

Lens Mount: ARRI PL

Sensor Resolution: Effective: 35.4 Megapixels (8192 x 4320)

Sensor Type: 40.96 x 21.6 mm (Vistavision) CMOS

Image Stabilization: None

Built-In ND Filter: Mechanical Filter Wheel with Clear, 2 Stop (1/4), 3 Stop (1/8), 4 Stop (1/16), 5 Stop (1/32), 6 Stop (1/64), 7 Stop (1/128) ND Filters

Internal Filter Holder: No

Capture Type: Video Only

Exposure Control

Shutter Type: Electronic Rolling Shutter

Advertised Dynamic Range: 17 Stops

Internal Recording Modes:

REDCODE HQ

8192 x 4320 up to 59.94 fps

6144 x 3240 up to 96 fps

4096 x 2160 up to 239.76 fps

2048 x 1080 up to 480 fps

REDCODE MQ

8192 x 4320 up to 59.94 fps

6144 x 3240 up to 160 fps

4096 x 2160 up to 239.76 fps

2048 x 1080 up to 480 fps

REDCODE LQ

8192 x 4320 up to 119.88 fps

6144 x 3240 up to 160 fps

4096 x 2160 up to 239.76 fps

2048 x 1080 up to 480 fps

REDCODE RAW

8192 x 4320 up to 119.88 fps

7168 x 3780 [140]

6144 x 3240 up to 160 fps

5120 x 2700 [192]

4096 x 2160 up to 239.76 fps

3072 x 1620 [320]

2048 x 1080 up to 480 fps

Sensor Crop While Recording: Various resolutions and aspect ratios supported when recording in RAW

Variable Frame Rates

Detailed frame rate options available up to DCI 2K resolution

Gamma Curve: RED IPP2

Recording Limit: Unlimited

Built-In Microphone: Mono

Audio Recording: 2-Channel 24-Bit 48 kHz

IP Streaming: MJPEG: 1920 x 1080

Interface

Media/Memory Card Slot: Single Slot: CFexpress Type B (CFast 2.0)

Video I/O: 3 x BNC (12G-SDI) Output, 1 x BNC (3G-SDI) Output, 1 x Proprietary Output

Audio I/O: 1 x LEMO 5-Pin Mic/Line (+48 V Phantom Power) Input, 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output

Power I/O: Various power outputs including LEMO 4-Pin, D-Tap, and Fischer 3-Pin

Other I/O: 1 x BNC (Genlock), 1 x LEMO 5-Pin (Timecode), 1 x 9-Pin (Ethernet) Control/Data Input/Output, 1 x USB-C

Wireless: 2.4 / 5 GHz Wi-Fi Video Output

Global Positioning: None

Monitor

Size: 2.4"

Display Type: Fixed LCD

Viewfinder

Type: Optional, Not Included

Focus

Focus Type: Auto and Manual Focus

Environmental

Operating Temperature: 32 to 72°F / 0 to 40°C

Storage Temperature: -4 to 122°F / -20 to 50°C

Storage Humidity: 0 to 85%

General

Battery Type: V-Mount

Tripod Mounting Thread: None

Material of Construction: Aluminum

Dimensions (W x H x D): Not Specified by Manufacturer

Weight: 7.99 lb / 3.62 kg
