RED V-RAPTOR XL 8K VV (Gold Mount)

The Gold Mount V-RAPTOR XL 8K VV Production Pack from RED DIGITAL CINEMA enhances the capabilities of the V-RAPTOR XL 8K VV camera with a comprehensive selection of accessories. This pack includes the V-RAPTOR 8K VV camera along with a range of essential items tailored for professional use. Below, each component of this kit is detailed for your convenience.

RED DIGITAL CINEMA V-RAPTOR XL 8K VV Cinema Camera (Gold Mount)

The Gold Mount V-RAPTOR XL 8K VV Camera from RED DIGITAL CINEMA delivers exceptional 8K VV multiformat video capture, coupled with REDCODE raw and Apple ProRes recording capabilities. Designed for high-end production, this camera features a streamlined form with a host of interfaces suitable for professional crew use. Key features include internal ND filters, an interchangeable lens mount with an included ARRI PL mount, and standard interfaces such as 12G/6G/3G-SDI outputs, 12 and 24V power outputs, and a Gold mount battery plate.

RED DIGITAL CINEMA DSMC3 RED Touch 7.0" LCD Monitor (Direct Mount)

The DSMC3 RED Touch 7.0" LCD Monitor from RED DIGITAL CINEMA is an ideal onboard monitor solution for DSMC3 camera rigs, including the V-RAPTOR 8K VV. Featuring daylight viewing capabilities and a wide 100% DCI-P3 color gamut, this touchscreen monitor offers high-quality imaging with a resolution of 1920 x 1200 and a brightness of 1300 cd/m². With direct mounting using the Pogo mount, this monitor provides seamless integration with your camera setup and offers versatile connectivity options.

RED DIGITAL CINEMA Compact Dual Battery Charger (Gold Mount)

Charge your Gold mount batteries conveniently on location with the RED Compact Dual Gold Mount Battery Charger. This charger, designed in collaboration with Core SWX, supports two Gold mount REDVOLT MICRO-G or REDVOLT XL-G batteries at a 3A rate. Compatible with various Gold mount batteries, this compact charger ensures reliable power for extended shooting sessions.

RED DIGITAL CINEMA REDVOLT XL-G Battery (156Wh, Gold Mount)

The REDVOLT XL-G Battery provides robust power for your V-RAPTOR XL or other Gold mount cameras. With a capacity of 156Wh, this battery automatically adjusts its output voltage to match your camera's requirements, offering flexibility and reliability. Developed in partnership with Core SWX, this battery is engineered for compatibility and high performance, making it an essential component of your camera kit.

RED DIGITAL CINEMA 2TB PRO CFexpress 2.0 Type B Memory Card

Capture high-quality footage with confidence using the 2TB PRO CFexpress 2.0 Type B Memory Card from RED. Certified for use with RED V-RAPTOR camera systems, this card ensures reliable performance with reduced power consumption and protection against overheating. With a capacity of 2TB and maximum read/write speeds of 800 MB/s, this card supports a wide range of resolutions and frame rates, making it an indispensable accessory for professional cinematography.

RED DIGITAL CINEMA V-RAPTOR XL Top Handle with Extensions

Customize your camera rig setup with the V-RAPTOR XL Top Handle with Extensions from RED DIGITAL CINEMA. This modular handle includes 1-inch, 3-inch, and 5-inch extensions, offering flexibility in handle length based on your shooting needs. With a start/stop button and multiple mounting threads, this handle provides convenience and versatility for comfortable handling and accessory attachment.

RED DIGITAL CINEMA V-RAPTOR XL Riser Plate (15mm & 19mm Studio)

Elevate your camera setup to the optimal height with the V-RAPTOR XL Riser Plate from RED DIGITAL CINEMA. Compatible with both 15mm and 19mm studio baseplates, this riser plate ensures proper alignment for mounting lenses and accessories. Equipped with various mounting threads, it offers seamless integration into your camera rig setup for enhanced stability and functionality.

RED DIGITAL CINEMA Top 15mm LWS Rod Support Bracket for V-RAPTOR XL

Attach compatible accessories to your RED V-RAPTOR XL camera using the Top 15mm LWS Rod Support Bracket from RED DIGITAL CINEMA. Designed for secure mounting on top of your camera, this bracket enables the attachment of 15mm LWS rod-mounted accessories such as lens motors or viewfinder brackets, enhancing the versatility of your camera setup.

RED DIGITAL CINEMA DSMC3 5-Pin to Dual XLR 3-Pin Adapter

Expand your audio recording capabilities with the DSMC3 5-Pin to Dual XLR 3-Pin Adapter from RED DIGITAL CINEMA. This adapter allows you to connect two XLR inputs to your V-RAPTOR camera, providing flexibility for capturing high-quality audio. With support for 48V phantom power and both mic and line-level inputs, this adapter ensures professional-grade audio recording for your productions.

RED DIGITAL CINEMA Hood for DSMC3 RED Touch 7" LCD

Enhance visibility and reduce glare on your DSMC3 RED Touch 7" LCD monitor with the Hood from RED DIGITAL CINEMA. Designed to improve viewing in bright outdoor conditions, this folding hood mounts easily onto the monitor using captive M3 screws, ensuring optimal viewing comfort and clarity during shoots.

By incorporating these accessories into your workflow, the Gold Mount V-RAPTOR XL 8K VV Production Pack offers a comprehensive solution for professional cinematography, providing essential tools to elevate your production quality and efficiency.

Package Contents:

• 1x V-RAPTOR XL 8K VV Camera (Gold Mount)
• 1x V-RAPTOR XL PL Mount
• 1x V-RAPTOR XL PL Mount Shim Pack
• 1x RED AC Power Adapter 270W
• 1x 3-Pin XLR to 4-Pin 2B Power Cable (10 feet)
• 1x RED Logo Sticker
• 1x V-RAPTOR XL Information Card (includes registration and support information)
• 1x 2-Year Standard Warranty

Specifications:

Imaging:

Lens Mount: ARRI PL

Sensor Resolution: Effective: 35.4 Megapixel (8192 x 4320)

Sensor Type: 40.96 x 21.6 mm (Vistavision) CMOS

Image Stabilization: None

Built-In ND Filter: Mechanical Filter Wheel with Clear, 2 Stop (1/4), 3 Stop (1/8), 4 Stop (1/16), 5 Stop (1/32), 6 Stop (1/64), 7 Stop (1/128) ND Filters

Internal Filter Holder: No

Exposure Control:

Shutter Type: Electronic Rolling Shutter

Advertised Dynamic Range: 17 Stops

Internal Recording Modes:

REDCODE HQ

8192 x 4320 up to 59.94 fps

6144 x 3240 up to 96 fps

4096 x 2160 up to 239.76 fps

2048 x 1080 up to 480 fps

REDCODE MQ

8192 x 4320 up to 59.94 fps

6144 x 3240 up to 160 fps

4096 x 2160 up to 239.76 fps

2048 x 1080 up to 480 fps

REDCODE LQ

8192 x 4320 up to 119.88 fps

6144 x 3240 up to 160 fps

4096 x 2160 up to 239.76 fps

2048 x 1080 up to 480 fps

REDCODE RAW

8192 x 4320 up to 119.88 fps

7168 x 3780 [140]

6144 x 3240 up to 160 fps

5120 x 2700 [192]

4096 x 2160 up to 239.76 fps

3072 x 1620 [320]

2048 x 1080 up to 480 fps

Sensor Crop While Recording:

Various resolutions in different aspect ratios

Variable Frame Rates:

Up to 8K: 119.88 fps

Up to 7K: 140 fps

Up to 6K: 160 fps

Up to 5K: 192 fps

Up to DCI 4K: 240 fps

Up to 3K: 320 fps

Up to DCI 2K: 480 fps

Gamma Curve: RED IPP2

Recording Limit: Unlimited

Built-In Microphone Type: Mono

Audio Recording: 2-Channel 24-Bit 48 kHz

IP Streaming: MJPEG: 1920 x 1080

Interface:

Media/Memory Card Slot: Single Slot: CFexpress Type B (CFast 2.0)

Video I/O: 3 x BNC (12G-SDI) Output, 1 x BNC (3G-SDI) Output, 1 x Proprietary Output

Audio I/O: 1 x LEMO 5-Pin Mic/Line (+48 V Phantom Power) Input, 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output

Power I/O: Various LEMO and D-Tap Outputs

Other I/O: Genlock, Timecode, Ethernet Control/Data, USB-C

Wireless: 2.4 / 5 GHz Wi-Fi Video Output

Monitor:

Display Size: 7.0" / 17.8 cm

Screen Resolution: 1920 x 1200

Touchscreen: Yes

Maximum Brightness: 1300 cd/m2

Color Gamut: 100% DCI-P3

RED DIGITAL CINEMA Compact Dual Battery Charger (Gold Mount):

Mount / Series Type: Gold Mount, REDVOLT, REDVOLT XL

Number of Battery Bays: 2

Electrical: AC Input Power: 100 to 240 VAC, 50 / 60 Hz

RED DIGITAL CINEMA REDVOLT XL-G Battery (156Wh, Gold Mount):

Mount / Series Type: Gold Mount

Battery Capacity: 156 Wh

Output Voltage: 12 VDC, 24 VDC

RED DIGITAL CINEMA 2TB PRO CFexpress 2.0 Type B Memory Card:

Card Type: CFexpress Type B

Storage Capacity: 2 TB

Read Speed: Maximum: 800 MB/s

Write Speed: Maximum: 800 MB/s

RED DIGITAL CINEMA V-RAPTOR XL Top Handle With Extensions:

Item Type: Topside Handle

Built-In Controls: Remote Trigger

RED DIGITAL CINEMA V-RAPTOR XL Riser Plate (15mm & 19mm Studio):

Compatibility: RED DIGITAL CINEMA V-RAPTOR XL

RED DIGITAL CINEMA Top 15mm LWS Rod Support Bracket For V-RAPTOR XL:

Rod Standard: 15 mm LWS / 60 mm Spacing

RED DIGITAL CINEMA DSMC3 5-Pin To Dual XLR 3-Pin Adapter:

Compatibility: RED V-RAPTOR

Audio I/O: 2 x XLR 3-Pin Mic/Line Input, 1 x DSMC3 RED 5-Pin Mic/Line Output

RED DIGITAL CINEMA Hood For DSMC3 RED Touch 7" LCD:

Compatibility: RED DIGITAL CINEMA DSMC3 Touch 7" LCD
