Garmin Tread Audio System with 2 Additional Speakers

Introducing the Garmin Tread Audio System, now with two extra speakers for an exceptional listening experience! Specially crafted for off-road powersport vehicles, our audio system ensures unparalleled sound quality, perfectly accompanying you on every thrilling adventure. Whether you're traversing rocky terrains or trailblazing through the wild, the Tread audio system delivers rich, dynamic sound in any situation. Take your off-roading experience to new heights with the dependable audio performance you deserve. Don't just ride; elevate your senses with the Garmin Tread Audio System!

Description

  • Options for audio sources include AM/FM, AUX and BLUETOOTH® technology.
  • The built-in speaker LEDs let you control and even sync colors to your music.
  • Enjoy the flexible setup designed for any side-by-side or other off-road vehicle.
  • Pairs with the Tread® app on your compatible smartphone or Tread® device to display music and settings.
  • The rugged design helps withstand bumpy rides and weather conditions, so your music never skips a beat.
  • A wireless remote is included for convenient control.

RUGGED DESIGN

The IP67 design is built to withstand dust, water and weather conditions, so your music will keep playing through rough terrain.

FULL AUDIO SYSTEM

Get everything you need for music: two 6.5” XS-LED tower speakers, the Tread audio box with LED controller and a wireless remote.

MULTIPLE AUDIO SOURCES

Enjoy quality audio from multiple sources, including AM/FM radio, AUX and even BLUETOOTH.

CUSTOM LED SPEAKERS

Choose from thousands of colors for your speakers. You can even sync your speakers to pulse to your music. When paired with your Tread navigator (sold separately), you can sync to your vehicle speed, or match your vehicle’s marker on the map for group rides.

WIRELESS REMOTE

Control your music with the included wireless remote that controls volume, track and audio source.

Easy-to-use audio.

PAIR WITH TREAD APP

Pair with the Tread app on your compatible smartphone for full control, and see a display showing music settings.

PAIR WITH TREAD DEVICE

Pair with any rugged Tread all-terrain navigation (sold separately) device to control audio, show music settings and more.

FLEXIBLE SETUP

A universal design is built for any side-by-side or off-road powersport vehicle.

Tread Audio Bundles

AUDIO SYSTEM PLUS 2 MORE SPEAKERS

More speakers means more music. This bundle includes four speakers, the stereo black box with LED controller and one wireless remote.

AUDIO SYSTEM PLUS SUBWOOFER

Bring the rumble with this bundle, which includes two speakers, a subwoofer with RGB LED lighting, the stereo black box with LED controller and one wireless remote.



IN THE BOX

Tread Audio Box with LED controller

Four 6.5" XS-LED tower speakers with tube mounts

Wireless remote

Wiring

Documentation



Audio Box

Weight 997 g (2.2 lbs)

Physical Dimensions (LxWxH) 210 mm x 130 mm x 55 mm (8.27" x 5.12" x 2.165")

Water and dust rating IP67

Input voltage 8 to 14.4 Vdc

Current (max) 40 A

Current (muted) less than 650 mA

Operating temperature range -4° F to 158° F (-20° to 70° C)

Storage temperature range -40° F to 185° F (-40° to 85° C)

Compass safe distance 203 mm (8")

BLUETOOTH wireless range up to 10 m (30 ft)

ANT wireless range up to 10 m (30 ft)

Fuse 15 A mini-blade type

Peak power (Watts) Four 200 W per channel

RMS power (Watts) Four 100 W RMS at 14.4 Vdc input, 4 ohm

Warranty 1 year

Speakers

Weight 2.49 kg (5.5 lbs)

Physical Dimensions 177 mm x 233 mm (6.97" x 8.78")

Water and dust rating IP67

Operating temperature range 32° - 122° F (0° to 50° C)

Speaker size 6.5"

Peak power (Watts) 200 W per speaker

RMS power (Watts) 50 W

Sensitivity (1 W/1 m) 91 db

Frequency response 80 Hz - 18kHz

Nominal impedance 4 ohms

Recommended amplifier power (RMS) 20 - 150 W

LED lighting yes (RGB)

LED supply voltage 10.8 - 16 Vdc

LED load current @ 14.4 VDC 150 mA

Voice coil diameter 30 mm (1.18")

Cone material polypropylene (PP) cone with cloth surround

Tweeter type aluminum dome

Supported roll bar sizes 33.4 mm (1.31") to 50.8 mm (2.00") outer diameter

Warranty 1 year

Wiring 3 m
