Omegon Camera veTEC 410 C Color

Introducing the Omegon veTEC 410 C, a cutting-edge full-frame color camera designed for high-performance astrophotography:

Key Features:

• Full-Frame Sensor: Capture expansive views of wide nebulas, star fields, and lunar landscapes with the large sensor size.
• Large Pixels (5.9 µm): Ensures optimal sensitivity and detail retention, particularly in low-light conditions.
• High Quantum Efficiency (~80%): Maximize light-gathering capability for enhanced image quality.
• Low Readout Noise (~1e-): Achieve clean, noise-free images with minimal interference.
• High Full-Well-Capacity: Choose between 20,000 e- (HCG) or 100,000 e- (LCG) capacity to accommodate varying exposure needs.
• ADC: 14-bit: Deliver precise color reproduction and tonal gradation for lifelike images.
• Zero-Amp-Glow: Eliminate amplifier glow for pristine image quality, free from unwanted artifacts.

Professional Deep-Sky Astrophotography: With its full-frame sensor, this camera excels at capturing wide nebulas, star fields, and lunar surfaces, offering unparalleled clarity comparable to DSLR cameras.

Thermoelectric Cooling: Reduce image noise effectively with the advanced cooling system, capable of maintaining temperatures up to 35°C below ambient. Precise temperature control facilitates accurate calibration with dark frames, resulting in exceptionally clean final images.

USB Hub: Simplify your astrophotography setup with two integrated USB ports, reducing cable clutter and allowing seamless daisy-chaining of additional devices such as guiding cameras.

Versatile Adaptability: Compatible with a wide range of astrophotography setups, thanks to its T2 thread and short back focus of 17.5mm. The included 2" nosepiece adapter ensures hassle-free connection to telescopes.

Robust Portability: Transport and store your valuable camera with confidence using the provided sturdy carrying case, complete with a custom-fit foam inlet for optimal protection.

Professional Planetary, Lunar, and Solar Astrophotography: Capture stunning details of celestial objects, including Jupiter's moons, Saturn's rings, lunar mountain ranges, and solar prominences, with high framerates and USB3.0 connectivity.

Transmission: Equipped with a filter window to shield the sensor chamber from dust and humidity. Color cameras feature an infrared-blocking filter for accurate color representation, while mono cameras offer versatile transmission control for advanced applications.

Compatibility: Seamlessly integrate the camera with popular astrophotography programs via ASCOM and INDI interfaces. Enjoy native compatibility with leading software suites such as PHD2 and N.I.N.A.

Scope of Delivery:

• Camera
• USB 3.0 Cable
• 12V 3A Power Supply (EU-Plug)
• Sturdy Carrying Case
• Desiccant Plug
• M48 / 2" Adapter
• M48 Extension (for 55mm backfocus)
• T2 Adapter Ring

Specifications:

Capacity: Full Frame

Sensor Type: CMOS Chip (Sony IMX410)

Sensor Size: 24 x 36 mm

Sensor Diagonal: 43.3 mm

Pixel Size: 5.94 µm

Resolution: 6064 x 4040 pixels

Megapixel: 24 MP

Bit Depth: 14 bits

Frame Rate: 15 fps (at full resolution)

Color Camera: Yes

Active Cooling: Yes

Max. Cooling Difference Below Room Temperature: -35°C

Power Supply: 12V (3A)

Interfaces: USB 3.0 (2x USB 2.0 Hub)

Autoguider: No

Supported Operating Systems: Windows 10/11, Linux (INDI)

Telescope Connection: M54

Filter Thread: Yes (2")

Flange Focal Distance: 17.5 mm

Binning: 2x2, 3x3, 4x4 (Digital)

Buffer Memory: 512 MB DDR3 RAM

Shutter: Rolling Shutter

Equipment: Filter Wheel (No), Transport Cases (Yes), Power Pack (Yes)

Cable: USB

Series: veTEC

Length: 103 mm

Diameter: 89 mm

Weight: 718 g

Outer Material: Aluminum

Color: Bronze

Type: Camera

Type of Build: Astronomical Cameras

Area of Application: Autoguider (No), Moon & Planets (Yes), Nebulae & Galaxies (Yes)
