AGM Seeker 25-384 Thermal Imaging Monocular
zoom_out_map
chevron_left chevron_right

Our company is involved in preparing official permits from the Polish Ministry of Development and Technology, which allows us to export all dual-use drones, optics, and portable radiophones without VAT on the Polish side / and without VAT on the Ukrainian side.

AGM Seeker 25-384 Thermal Imaging Monocular

Introducing the AGM Seeker Thermal Monocular series, the latest addition to the world's most comprehensive thermal imaging lineup. The Seeker series features a range of germanium lens sizes and is equipped with an industry-leading 384x288 resolution thermal detector with a 12-micron pixel pitch and sub-20mK thermal sensitivity. PART NO.: SEEK25-384

1722.00 $
Tax included

1400 $ net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

Introducing the AGM Seeker Thermal Monocular series, the latest addition to the world's most comprehensive thermal imaging lineup. The Seeker series features a range of germanium lens sizes and is equipped with an industry-leading 384x288 resolution thermal detector with a 12-micron pixel pitch and sub-20mK thermal sensitivity. Building on user feedback from the original Taipan monoculars, the Seeker series introduces several key upgrades: a removable 18650 rechargeable battery, an improved sub-20mK thermal sensor, and a 90-degree tilt sensor that turns off the display to conserve battery life.

The Seeker series is also enhanced with numerous software improvements and familiar AGM thermal features, including: F1.0 aperture optics, a 50Hz refresh rate, 16GB of built-in memory, Wi-Fi compatibility for pairing with the AGM Connect App, an IP67 waterproof rating, a USB Type-C port for external power, and four color palettes. The wider rubber eyepiece ensures comfortable viewing of the 1024 OLED display, making it ideal for extended use in the field. The Seeker series is designed for versatile applications such as hunting, farming/herd protection, law enforcement, search & rescue, boating, camping, and other outdoor activities.

Key Features:

  • 12μm, 384x288 resolution thermal detector
  • Exceptional thermal sensitivity (NETD <20mK)
  • Advanced image processing with Digital Detail Enhancement, digital Noise Reduction, and NLM algorithm
  • 50 Hz image frame rate
  • 1024x768 resolution OLED display
  • 64 GB built-in memory for video recording and image capture
  • Wi-Fi hotspot capability
  • Digital zoom options: 1x, 2x, 4x, 8x
  • Replaceable and rechargeable Li-Ion battery with up to 7 hours of life
  • External power supply capability
  • Rugged, waterproof housing with rubber overmolding
  • 3-year warranty



Package Includes:

  • Battery Charger
  • USB Cable
  • 2x 18650 Rechargeable Batteries
  • Power Adapter (US and EU plugs)
  • Protective Bag
  • Wrist Strap
  • User Manual



Specifications:

Detector Type: 12μm Vanadium Oxide Uncooled Focal Plane Array

Resolution: 384x288

Refresh Rate: 50 Hz

Response Waveband: 8μm to 14μm

NETD: ≤20 mK (@25°C), F#=1.0

Detection Range (for 6’ object): 780 m

Lens System: 25 mm; F1.0

Field of View (H × V): 10.5° × 7.9°

Magnification: 2.5x - 20x

Digital Zoom: 1x, 2x, 4x, 8x

Diopter Adjustment: -5 to +3 dpt

Monitor: 1024x768 OLED

FFC (Flat Field Correction): Auto, Manual, External Correction

Palettes: Black Hot, White Hot, Red Hot, Fusion

Image Boost: Yes

Highest Temperature Spot Tracking: Yes

Wi-Fi Hotspot: Yes

Standby Mode: Yes

Storage: Built-in 64 GB memory

Video Recording: Yes (on-board)

Image Capture: Yes

Battery Type: One replaceable rechargeable 18650 Lithium battery

Battery Life: 6.5 hours

Power: 5 VDC/2 A, 1.75 W

Interface: USB Type-C

Working Temperature: -30°C to 55°C (-22°F to 131°F)

Protection Level: IP67

Dimensions: 171 × 61 × 57 mm (6.73 × 2.4 × 2.2 in)

Weight: 0.32 kg (0.73 lb)
