AGM Rattler V2 35-384 thermal weapon sights

We've enhanced our best-selling thermal scope with the all-new AGM RattlerV2 35-384. This advanced model features a 35mm Germanium lens and a 384 x 288 resolution thermal sensor, offering a base magnification of 3x and an impressive detection range of up to 1800 meters/yards. PART NO.: 314204550205R331

2978.13 $
Tax included

2421.24 $ net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

We've enhanced our best-selling thermal scope with the all-new AGM RattlerV2 35-384. This advanced model features a 35mm Germanium lens and a 384 x 288 resolution thermal sensor, offering a base magnification of 3x and an impressive detection range of up to 1800 meters/yards. Among the 384-resolution options, the RattlerV2 35-384 delivers a higher base magnification and a slightly narrower field of view (7.5° × 5.6° or 40 feet at 100 yards), providing a perfect balance of broad scanning coverage and superior target identification at greater distances.

The RattlerV2 35-384 enhances familiar AGM Rattler features with new, game-changing upgrades. It includes an upgraded battery compartment that accommodates a rechargeable battery, extending operational time to 11 hours. Additionally, the scope features a cutting-edge 12-micron thermal sensor with the highest sensitivity rating (sub-20 mK) on the market.

Key features include Shot Activated Recording (SAR), a user-friendly simplified menu, and 10 versatile reticle options with multiple zeroing profiles for various calibers and rifles. The scope also comes with a custom ADM QD Mount for effortless attachment and detachment, Wi-Fi hotspot connectivity through the AGM app, and a raised 5-button control layout designed for easy navigation, even while wearing gloves.

Key Features:

  • Upgraded Scope Body Design
  • 35mm Germanium lens
  • 384 x 288 resolution thermal sensor
  • Magnification range: 3× - 24×
  • Digital zoom: 1×, 2×, 4×, 8×
  • Detection range up to 1800 meters/yards
  • Field of View: 7.5° × 5.6° (40 feet at 100 yards)
  • 50 Hz Refresh Rate
  • Enhanced focus ring with short throw
  • Upgraded Lens Cap
  • Rechargeable battery with up to 11 hours of run time
  • Shot Activated Recording
  • Video and Audio Recording
  • Simplified menu layout for intuitive use
  • 10 reticle options with customizable zeroing profiles
  • Custom ADM QD Mount for easy scope removal and reattachment
  • Wi-Fi hotspot connectivity through AGM app
  • Raised 5-button control layout for ease of use with gloves



Package Includes:

  • AGM/ADM 2120 QRM Mount
  • Two Rechargeable Batteries
  • Charger
  • USB Cable
  • Lens Cloth
  • Manual
  • Carrying Case



Specifications:

Detector Type: 12μm VOx Uncooled Focal Plane Array

Resolution: 384 × 288

NETD: Less than 20 mK (25°C, F# = 1.0)

Refresh Rate: 50 Hz

Lens System: 35 mm; F/1.0

Magnification: 3× - 24×

Field of View: 7.5° × 5.6°

Diopter Adjustment: -5 to +5 diopters

Focus Range: 2 m to infinity

Exit Pupil: 6 mm

Eye Relief: 45 mm

Digital Zoom: 1×, 2×, 4×, 8×

Detection Range (6’ object): 1800 m/yd

Display: 0.39-inch, OLED, 1024×768

Palettes: Black Hot, White Hot, Red Hot, Fusion

Flat Field Correction: Auto, Manual, External Correction

Scene Modes: Cold, Warm

Boresight Adjustment: Digital Controlled

Video/Audio Recording: Yes

Image Capture: Yes

Standby Mode: Yes

Storage: Built-in EMMC (16 GB)

PIP (Picture-in-Picture): Yes

Defective Pixel Correction: Yes

Wi-Fi Hotspot: Yes

Hot Track: Yes

Reticle Options: 10 types, 4 colors, on/off

Distance Measurement: Yes (Stadiametric)

Shot Activated Recording (SAR): Yes

Battery Type: Replaceable and rechargeable Li-ion battery

Battery Life (Operating, 20°C): Up to 11 hours (25°C, with hotspot off)

External Power Supply: 5 VDC, 2 A, USB Type-C

Operating Temperature Range: -30°C to +55°C (-22°F to 131°F)

Protection Level: IP67

Max. Recoil: 1000 g/0.4 ms

Weight (without mount and battery): 0.51 kg (1.13 lb)

Dimensions (without mount): 221 × 68 × 67 mm (8.7 × 2.7 × 2.6 in)
