Berlebach Wooden tripod model 342 (8074)

The Modular Report Tripod System is a versatile and professional tripod designed for photography and videography. Its lightweight magnesium mounting head serves as the base for ten interchangeable module inserts, allowing users to adapt the tripod to various applications. The module inserts can be easily replaced using the special wrench included in the delivery. The cone fixation ensures a secure, positive-locking, and clearance-free connection between components, providing excellent stability during use.

Thanks to the advanced stop system, users can set angles of spread at approximately 20°, 40°, 60°, 80°, and 100° using a wing catch. This system guarantees that the tripod maintains its specified load capacity even when the legs are fully inclined.

This tripod is equipped with Module Insert 4, which includes a center column measuring 50 cm in length and 25 mm in diameter, made of precision-drawn light-metal tubing, and a leveling ball. The center column also features a rotating panorama plate, allowing the leveling ball to tilt by 30° in all directions. The aluminum support plate has a diameter of 68 mm and is equipped with a fixed fastening screw (size selectable) along with three locking screws to prevent unintentional loosening of the mounted system. A built-in spirit level ensures quick and precise adjustments.

For near-ground-level work, an extra-short center column (10 cm) can be used. The specified maximum height applies when the 50 cm center column is fully extended.

Specifications

Capacity

• Type of build: Tripod

• Maximum tripod height: 196 cm

• Load capacity: 10 kg

• Carrying length: 92 cm

Material and Construction

• Type: Camera and video tripod

• Material: Wood

• Number of leg extensions: 1

• Leg extension adjustment: Twist lock

• Tripod pad type: Rubber foot (synthetic material)

• Measures of accessory tray: Not included (without accessory tray)

Special Features

• Number of levels: 1

• Single-handed operation: Yes

• Tripod head included in contents: No

• Carrying bag included in contents: Not included

• Integrated wedge included: Not included

• Panorama scale included: Not included

• Accessory plate included: Not included

• Central column included: Yes

• Quick-release plate included: Not applicable

General Information

• Weight: 3.4 kg

• Series: Report

• Color: Nature

• Height range (cm): 53 - 196

• Length (cm): Not specified

• Width (cm): Not specified
