Euromex Objective Lens, AX.7300, Infinity EIS 60 mm, semi-plan Pli- Apo Fluarex S100x/1.25 oil, M25, 0.18 mm (84250)

The Euromex Objective Lens AX.7300 is a high-end microscope objective designed for advanced biological applications, particularly in fluorescence microscopy. This lens is part of the Achios-X series and features semi-plan apochromatic optics, providing superior color correction and flat-field imaging. With its high numerical aperture and oil immersion capability, it offers exceptional resolution and light-gathering ability, making it ideal for detailed cellular and subcellular observations in biological research.

Euromex Objective Lens AX.7300 Specifications:

General Information:

• Series: Achios-X

• Field of application: Biology (yes)

Optical Characteristics:

• Type: Infinity EIS (Ergonomic Infinity System)

• Magnification: 100x

• Numerical Aperture (NA): 1.25

• Immersion: Oil

• Working Distance: 0.18 mm

Physical Properties:

• Thread size: M25

• Optical Design: Semi-plan PLi-Apo Fluarex S (Semi-plan Apochromatic, Fluorescence-optimized, Spring-loaded)

Additional Features:

• Tube Length: 60 mm

• Correction: Infinity-corrected

This objective lens is specifically designed for high-resolution fluorescence microscopy, offering excellent color correction and image quality. Its apochromatic design minimizes chromatic aberrations, while the high numerical aperture allows for maximum light collection, crucial for fluorescence applications in biological research.
