Euromex Objective Lens, AX.7340, Infinity EIS 60 mm, semi-plan Pli- Apo Fluarex S40x/0.75, M25, 1.36 mm (84249)

The Euromex Objective Lens AX.7340 is a precision-engineered microscope objective designed for advanced biological applications, particularly in fluorescence microscopy. As part of the Achios-X series, this lens combines semi-plan apochromatic optics with a high numerical aperture to deliver exceptional resolution and color correction. With its 40x magnification and optimized working distance, it is ideal for detailed imaging of biological specimens, ensuring accurate and reliable results.

Euromex Objective Lens AX.7340 Specifications:

General Information:

• Series: Achios-X

• Field of application: Biology (yes)

Optical Characteristics:

• Type: Infinity EIS (Ergonomic Infinity System)

• Magnification: 40x

• Numerical Aperture (NA): 0.75

• Working Distance: 1.36 mm

Physical Properties:

• Thread size: M25

• Optical Design: Semi-plan PLi-Apo Fluarex S (Semi-plan Apochromatic, Fluorescence-optimized, Spring-loaded)

Additional Features:

• Tube Length: 60 mm

• Correction: Infinity-corrected

This objective lens is optimized for fluorescence microscopy, offering superior image quality with minimal chromatic aberrations. Its semi-plan apochromatic design ensures flat-field imaging, while the spring-loaded mechanism adds durability and protection during use. The infinity-corrected system ensures compatibility with modern microscopes, making it an excellent choice for professionals and researchers in biological sciences requiring high-resolution imaging at higher magnifications.
