Euromex Objective Lens, AX.7700, Infinity EIS 60 mm, plan-PH PLPHi 100x/1.25 oil, M25, 0.22 mm (84254)

The Euromex Objective Lens AX.7700 is a high-performance microscope objective designed for advanced biological applications, particularly in phase contrast microscopy. This lens is part of the Achios-X series and features plan phase contrast optics, providing excellent image quality and contrast for observing transparent specimens. With its high magnification and numerical aperture, it is ideal for detailed examination of cellular structures and other minute biological features.

Euromex Objective Lens AX.7700 Specifications:

General Information:

• Series: Achios-X

• Field of application: Biology (yes)

Optical Characteristics:

• Type: Infinity EIS (Ergonomic Infinity System)

• Magnification: 100x

• Numerical Aperture (NA): 1.25

• Immersion: Oil

• Working Distance: 0.22 mm

Physical Properties:

• Thread size: M25

• Optical Design: Plan-PH PLPHi (Plan Phase Contrast)

Additional Features:

• Tube Length: 60 mm

• Correction: Infinity-corrected

This objective lens is optimized for phase contrast microscopy, offering superior contrast and resolution for observing living cells and other transparent specimens. The plan optics ensure a flat field of view, while the oil immersion capability allows for maximum resolution. Its infinity-corrected design ensures compatibility with modern microscope systems, making it an excellent choice for researchers and professionals in biological sciences requiring high-quality imaging at high magnifications.
