Euromex objective BS.7210, Plan PL 10x/0.25, w.d. 17.9 mm (bScope) (77326)

The Euromex objective BS.7210 is a high-quality microscope objective designed for use with the bScope series microscopes. This Plan PL 10x/0.25 objective features plan optics for a flat field of view and a long working distance of 17.9 mm. It is ideal for applications requiring moderate magnification and a generous working space, such as routine laboratory work, educational settings, and general biological or material observations.

1149.02 kn
Tax included

934.16 kn net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

The Euromex objective BS.7210 is a high-quality microscope objective designed for use with the bScope series microscopes. This Plan PL 10x/0.25 objective features plan optics for a flat field of view and a long working distance of 17.9 mm. It is ideal for applications requiring moderate magnification and a generous working space, such as routine laboratory work, educational settings, and general biological or material observations.



This objective offers moderate magnification with a numerical aperture of 0.25, providing a good balance between field of view and resolution. The plan optics ensure that the entire field of view remains in focus, which is essential for accurate observation and imaging of specimens across the entire visible area. The long working distance of 17.9 mm allows for comfortable manipulation of specimens and is particularly useful when working with thicker samples or in situations requiring additional clearance. The achromatic design helps to minimize chromatic aberrations, resulting in clear and accurate images.



Specifications

Optics

  • Field Curvature: Plan

  • Cover Glass Correction: Yes

  • Suspension: No

  • Immersion Lens: No

  • Lens Type: Achromatic

  • Magnification: 10x

Capacity

  • Designed for Cover Glass Thickness: 0.17 mm

  • Brightfield: Yes

  • Numerical Aperture: 0.25

Mechanics

  • Working Distance: 17.9 mm

Special Features

  • Specimen Protection Spring: Not applicable

Compatibility

  • Matches Series: bScope

Miscellaneous

  • Supplier Product Number: BS.7210

Data sheet
