Euromex Objective IS.8100, 100x/0.90, PLMi IOS, plan, infinity (iScope) (53364)

The Euromex Objective IS.8100 is a high-magnification microscope objective designed for metallurgical and materials science applications. This 100x magnification objective features an infinity-corrected optical system and a plan apochromatic design, making it ideal for high-resolution imaging of reflective surfaces without the need for cover glass correction. It is part of the iScope series and offers exceptional resolution and contrast for detailed examination of metal surfaces, semiconductor materials, and other opaque specimens.

973.21 £
Tax included

791.23 £ net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

The Euromex Objective IS.8100 is a high-magnification microscope objective designed for metallurgical and materials science applications. This 100x magnification objective features an infinity-corrected optical system and a plan apochromatic design, making it ideal for high-resolution imaging of reflective surfaces without the need for cover glass correction. It is part of the iScope series and offers exceptional resolution and contrast for detailed examination of metal surfaces, semiconductor materials, and other opaque specimens.



This objective combines high magnification with a high numerical aperture of 0.90, allowing for exceptional resolution and light-gathering capabilities in reflected light applications. The plan apochromatic design (PLMi IOS) ensures sharp focus across the entire field of view, while the infinity-corrected optics provide flexibility in microscope configurations. The relatively long working distance of 2 mm for such a high magnification objective allows for easier focusing and manipulation of samples, which is particularly useful in metallurgical applications. The lack of cover glass correction makes this objective specifically suited for examining uncovered, reflective surfaces, typical in materials science and industrial inspection tasks.



Product Details:

Optics:

  • Magnification: 100x

  • Optical system: Infinity

  • Cover glass correction: No

  • Infinity corrected: Yes

Capacity:

  • Image scale: 100

  • Numerical aperture: 0.90

Mechanics:

  • Working distance: 2 mm

  • Compatible series: iScope

Miscellaneous:

  • Supplier product number: IS.8100

Data sheet

3VRS2JWXF5
