Evident Olympus Stereo zoom microscope SZ51, for gooseneck, bino (49364)

The SZ51 stereo microscope features ComfortView eyepieces that ensure fast and comfortable observation with pupil aberration control. The Greenough optical system's small angle convergence provides excellent image flatness and depth of focus. Superior optical coatings offer high color fidelity, while antistatic materials and coatings protect specimens from electrostatic discharge. The SZ61 zoom stereo microscope is ideal for routine and advanced stereo microscopic observations, particularly when digital imaging documentation is required.

16926.54 kn
Tax included

13761.41 kn net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

The SZ51 stereo microscope features ComfortView eyepieces that ensure fast and comfortable observation with pupil aberration control. The Greenough optical system's small angle convergence provides excellent image flatness and depth of focus. Superior optical coatings offer high color fidelity, while antistatic materials and coatings protect specimens from electrostatic discharge. The SZ61 zoom stereo microscope is ideal for routine and advanced stereo microscopic observations, particularly when digital imaging documentation is required. The cost-efficient SZ51 offers a wide range of functions for life sciences.

Wide Zoom Ratio

The SZ51 offers a magnification range of 8x to 40x (using 10x eyepieces) with a wide zoom ratio of 5:1.

3-Dimensional Viewing

The inward angle design ensures the right combination of flatness and depth of focus, enabling 3D viewing. Specimens with significant depth can be focused from top to bottom, allowing for faster inspection.

ComfortView Eyepieces for Reduced Eyestrain

These exclusive eyepieces ensure quick and comfortable observation by providing pupil aberration control and proper eyepoint positioning. Superior optical coatings deliver true color images with fine detail.

LED Illumination

The universal reflected/transmitted light LED illumination stand integrates flat, high-brightness LEDs into a slim base, facilitating easy specimen access and manipulation.

Electrostatic Discharge Protection

Antistatic materials and coatings on the main body and accessories quickly eliminate static electricity, protecting specimens from electrostatic damage during observation.

4 Available Sets

  • SZ51 without illumination (for use with gooseneck)

  • SZ51 without illumination (for use with ringlight)

  • SZ51 with transmitted light

  • SZ51 with incident and transmitted light



Specifications

  • Optics: Greenough optical system

  • Lighting: None included

  • Magnification: Up to 40x

  • Lens Type: Zoom lens

  • Eyepiece: 10x

  • Optical Zoom: 0.8–4x

  • Type of Build: Binocular

  • Viewing Posture: 45° viewing angle; interpupillary distance adjustable from 52–76 mm

  • Focusing: Coarse movement

  • Specimen Stage: Stage plate

  • Working Distance: 110 mm

  • Special Features: Filter holder included

General Information

  • Suitable Age: From 14 years old

  • Series: SZ51

Fields of Application

Industry, Medicine, Education, Biology, University, Semiconductor Technology, Odontotechnics, Marine Biology

Supplier product number: E0460025 (E07MIS0025)
