Evident Olympus Objective MPLN100X-1-7, M Plan, Achro, incident/transmitted light, 100x/0.9 wd 0.21mm (67409)
zoom_out_map
chevron_left chevron_right

Our company is involved in preparing official permits from the Polish Ministry of Development and Technology, which allows us to export all dual-use drones, optics, and portable radiophones without VAT on the Polish side / and without VAT on the Ukrainian side.

New

Evident Olympus Objective MPLN100X-1-7, M Plan, Achro, incident/transmitted light, 100x/0.9 wd 0.21mm (67409)

The Evident Olympus Objective MPLN100X-1-7 is a high-performance microscope objective lens designed for both incident and transmitted light applications in industrial settings. This objective is part of the MPLN series, which is known for its plan achromatic design, providing excellent image flatness and contrast across the entire field of view. With its high magnification of 100x and a numerical aperture of 0.9, this objective is ideal for detailed observations in industrial microscopy.

5172.94 $
Tax included

4205.64 $ net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

The Evident Olympus Objective MPLN100X-1-7 is a high-performance microscope objective lens designed for both incident and transmitted light applications in industrial settings. This objective is part of the MPLN series, which is known for its plan achromatic design, providing excellent image flatness and contrast across the entire field of view. With its high magnification of 100x and a numerical aperture of 0.9, this objective is ideal for detailed observations in industrial microscopy.



This objective lens is specifically designed for industrial applications, offering high magnification and a high numerical aperture for detailed imaging. Its plan achromatic design ensures a flat field of view with minimal chromatic aberration. The short working distance of 0.21 mm allows for high-resolution imaging of surface details. The lens is suitable for both incident and transmitted light microscopy, making it versatile for various industrial inspection and research applications.



Product Overview:

  • Name: Evident Olympus Objective MPLN100X-1-7, M Plan, Achro, incident/transmitted light

  • Supplier Product Number: N5186500

Optical Specifications:

  • Image Scale: 100x

  • Field Curvature: Plan

  • Cover Glass Correction: No

  • Colour Correction: Achromatic

  • Suspension: Yes

  • Immersion Lens: No

  • Infinity Corrected: Yes

  • Optical System: Infinity

Lighting:

  • Incident light and transmitted light compatible

Performance Characteristics:

  • Field of View Value: 0.22

  • Numerical Aperture: 0.9

  • Image Scale: 20

  • Magnification: 100x

Mechanical Properties:

  • Working Distance: 0.21 mm

Application and Features:

  • Series: MPLN

  • Contrast Method: Brightfield (Yes)

  • Field of Application: Industry (Yes), Medicine (Not specified)
