Evident Olympus PLN20XPH/0,4 Plan Achromat Phase Objective (49949)

The Evident Olympus PLN20XPH/0,4 is a plan achromat phase contrast objective designed for transmitted light observation in clinical settings. This objective is part of the PLN-PH series, which provides consistent image flatness up to F.N.22, making it ideal for clinical inspections and other applications requiring high-contrast imaging of transparent specimens.

1228.57 $
Tax included

998.84 $ net price (non-EU countries)

Anatolii Livashevskyi
Product Manager
Українська / Polski
+48721808900
+48721808900
Telegram +48721808900
[email protected]

Description

The Evident Olympus PLN20XPH/0,4 is a plan achromat phase contrast objective designed for transmitted light observation in clinical settings. This objective is part of the PLN-PH series, which provides consistent image flatness up to F.N.22, making it ideal for clinical inspections and other applications requiring high-contrast imaging of transparent specimens.



This objective is particularly suited for applications requiring moderate magnification and phase contrast capabilities. The plan achromatic design ensures a flat field of view with good color correction, providing clear and accurate imaging across the entire field. Its phase contrast feature makes it excellent for observing transparent or unstained biological specimens in clinical and research settings.



Key Features:

  • Part of the PLN-PH Series

  • Developed for transmitted phase-contrast light observation

  • Provides consistent image flatness up to F.N.22

  • Ideal for clinical inspections

Optical Specifications:

  • Image Scale: 20x

  • Field Curvature: Plan

  • Cover Glass Correction: Yes (0-1.00 mm)

  • Colour Correction: Achromatic

  • Suspension: No

  • Immersion Lens: No

  • Infinity Corrected: Yes

  • Optical System: Infinity

Performance Characteristics:

  • Numerical Aperture: 0.4

  • Image Scale: 20

  • Magnification: 20x

Mechanical Properties:

  • Working Distance: 1.2 mm

Additional Information:

  • Series: PLN

  • Supplier Product Number: N1216300

Data sheet

BSHVMEU08M
