Evident Olympus Objective UPLFLN60XOIPH-2/1,25 (61458)

The UPLFLN60XOPH/1.25 is a high-performance phase-contrast microscope objective designed for advanced research and clinical applications. This objective is part of the UPLFLN-PH series, known for its effectiveness in phase-contrast observations with high S/N ratio, resolution, and contrast imaging. It produces flat images with high transmission factors extending into the near-infrared spectrum.

This objective is particularly suited for applications requiring high magnification and phase contrast capabilities, such as detailed cellular studies, pathology, and advanced clinical diagnostics. Its variable numerical aperture allows for adjustable resolution and depth of field, making it versatile for various imaging needs. The oil immersion feature combined with phase contrast optimization enables high-resolution imaging with enhanced contrast, making it an ideal choice for cutting-edge microscopy techniques in both research and medical settings.

Key Features:

• Magnification: 60x

• Variable Numerical Aperture: 0.65-1.25

• Oil Immersion

• Plan Fluorite Design

• Phase Contrast Optimization

• Infinity-Corrected

Optical Specifications:

• Image Scale: 60x

• Field Curvature: Plan

• Cover Glass Correction: Yes (0-1.00 mm)

• Colour Correction: Achromatic

• Suspension: Yes

• Immersion Lens: Yes

• Infinity Corrected: Yes

• Optical System: Infinity

Performance Characteristics:

• Field of View Value: 26.5

• Image Scale: 60

• Magnification: 60x

Mechanical Properties:

• Working Distance: 0.2 mm

Compatibility:

• Series: UPLFLN

• Compatible with: CX33, CX43

Application:

• Field of Application: Medicine (Yes)

Additional Information:

• Supplier Product Number: N5704000
