Evident Olympus U-CTR30-2-2 Trinocular Tube (62194)

The Evident Olympus U-CTR30-2-2 Trinocular Tube is a high-quality microscope accessory designed for advanced optical applications. This trinocular tube features lead-free optics and is compatible with infinity-corrected optical systems. It is particularly useful for applications requiring both visual observation and digital imaging, such as in life sciences, materials science, and industrial quality control.

This trinocular tube is specifically designed for use with the CX43 microscope series, providing researchers and professionals with the ability to perform visual observations and capture images simultaneously. Its ergonomic design and high-quality optics make it an excellent choice for extended microscopy sessions in various scientific and industrial applications.

Key Features:

• 30° inclination for comfortable viewing

• Adjustable interpupillary distance from 48-75 mm

• Fixed 50/50 light distribution between eyepieces and camera port

• Adjustable diopter range (± 5 diopter) on left sleeve

• Compatible with WHB10x and WHB10x-H eyepieces (field number 20)

Specifications:

• Optical System: Infinity-corrected

• Eyepiece: 10x/20

• Type: Trinocular

• Compatible Series: CX43

Scope of Delivery:

• Trinocular photo tube U-CTR30-2-2 (microscope head)

Additional Information:

• Supplier Product Number: N1468400
