Scan Antenna VHF 73, 3dB

Introducing the Scan Antenna VHF73, a high-performance 3dB/2.1dBi marine VHF antenna designed to provide reliable communication at frequencies ranging from 146 to 162.5 MHz. With a length of 1260mm, this durable antenna ensures optimal signal strength and coverage for your vessel's communication needs. The VHF73 features a 1-inch nut for secure mounting and easy installation on boats, yachts, and other marine applications. Part Number 11073-002 ensures compatibility with various communication systems and devices. Upgrade your marine communication system with the Scan Antenna VHF73 and experience improved connectivity and clear communication while out on the water.
103.39 $
Tax included

84.06 $ net price (non-EU countries)

Karol Łoś
Product Manager
English / Polski
+48603969934
+48507526097
[email protected]

Description

High quality VHF antenna for professional use

Similar design available for the AIS and AM/FM bands

Full 1/2 λ dipole antenna design

Full omni-directional radiation pattern

No groundplane needed



Electrical specifications

FREQUENCY 146 - 162.5 MHz (International Maritime VHF-band a.o.)

BANDWIDTH 16.5 MHz

IMPEDANCE 50 ohm

VSWR < 1.5:1

POLARISATION Vertical

GAIN 3 dB (Marine), 0 dBd, 2.1 dBi

MAX. INPUT POWER 150 W

ANTISTATIC PROTECTION Direct Ground



Mechanical specifications

COLOR White and chrome

HEIGHT Approx. 1260 mm

WEIGHT 375 g

MOUNTING On 1" threaded pole (G1"-11 thread) with Revolving Nut Kit or on optionally brackets

MOUNTING PLACE On mast or deck

MATERIALS PU-painted glasfibre, copper, PTFE, PE and chrome plated solid brass

SURVIVAL WIND SPEED 55 m/s (125 mph)

OPERATING TEMPERATURE -55C to +70C (IEC 60068-2-1, IEC 60068-2-2)

CONNECTOR UHF-female

CABLE No cable supplied

INGRESS PROTECTION IP66

VIBRATION IEC 60068-2-6, IEC 60068-2-64

SERIAL NO. On product label

Data sheet
