TS Optics Telescope N 150/420 Hypergraph6 OTA (62508)

The TS Optics N 150/420 Hypergraph6 OTA is a compact, high-performance Newtonian reflector telescope designed for advanced amateur astronomers, especially those interested in astrophotography. With a fast focal ratio of f/2.8 and a hyperbolic primary mirror, this telescope provides a wide, fully corrected field ideal for capturing deep-sky objects, nebulae, and galaxies. Its robust aluminum construction and integrated corrector make it reliable and easy to use, while the lightweight design ensures portability for field observations and imaging sessions.

Optics
Type: Reflector
Design: Newtonian
Aperture: 150 mm
Focal Length: 420 mm
Aperture Ratio: f/2.8
Resolving Capacity: 0.92
Limiting Magnitude: 12.7
Light Gathering Power: 460
Maximum Useful Magnification: 300x
Tube Weight: 5 kg
Tube Diameter: 200 mm
Tube Length: 450 mm
Tube Material: Aluminium
Tube Construction: Full tube
Fully Corrected Field: 45 mm

Reflector
Main Mirror Construction: Hyperbolic
Secondary Mirror Design: Flat
Secondary Mirror Diameter: 70 mm

Focuser
Type: Rack and pinion
Eyepiece Connection: 1.25-inch
Camera-Side Thread: M48
Backfocus: 55 mm (@M48)
Free Aperture: 64 mm
Gear Reduction: Yes

Mount
Type: OTA (Optical Tube Assembly)
Mount Included: No

Included Accessories
Corrector: Integrated
Tube Clamps: Yes
Carrying Handle: Yes
Transport Case: No
Prism Rail: Vixen-Style
Finder Base: Vixen/Skywatcher Level

General
Series: Hypergraph

Area of Application
Astrophotography: Yes (very good)
Moon & Planets: Yes
Nature Observation: No
Nebulae & Galaxies: Yes
Sun: No (only with appropriate solar filter)

Recommended For
Beginners: No
Advanced Users: Yes
Observatories: No
